Hexagonal counterflow core
Hexagonal counterflow plastic plate exchangers deliver up to 90% thermal efficiency.
SenseAir
New-generation residential heat recovery with EC fans, Wi-Fi app control and up to 90% efficiency.
- 90%max. thermal efficiency
- 375m³/hairflow, SenseAir HV
- 4automatic operating modes
- ECmotor-driven fans
01Overview
Heat recovery for one home,
energy class A+.
The SenseAir casing is moulded EPP, which insulates well and keeps the unit to 18 kg.
The SenseAir HV model covers airflow requirements up to 375 m³/h, and comes standard with a G4 filter, bypass damper, and temperature and humidity sensors.
EC motor fans
EC fans draw 150 W at most. The unit is rated energy class A+.
Lightweight EPP body
New-generation EPP body design with high thermal insulation.
Flexible installation
Vertical or horizontal, left or right. One unit covers all four air directions.
Plug-and-play
G4 filter, bypass damper and temperature and humidity sensors as standard.
Wi-Fi & ModBus
Control by Wi-Fi and mobile app; ModBus for building automation integration.
02Operating modes
Four modes,
switched automatically.
SenseAir switches between four modes on its own: heat recovery, free cooling, humidity boost and defrost.
Heat recovery
Supply and extract air pass through the hexagonal counterflow exchanger, recovering up to 90% of the heat that would otherwise be lost.
At a glance
Free cooling
When the indoor–outdoor temperature difference is minimal in seasonal transitions, the internal bypass damper opens so fresh air enters without passing through the exchanger.
At a glance
Humidity boost
The built-in humidity sensor switches the unit to Boost when the preset level is reached, raising fan speed to prevent moisture build-up.
At a glance
Defrost
Below 0 °C outdoors, fan speeds are optimised to prevent internal icing. For extended freezing conditions an electric pre-heater is recommended.
At a glance
03Specifications
Technical overview.
- Series
- SenseAir, residential heat recovery
- Model
- SenseAir HV
- Airflow
- Up to 375 m³/h (≈ 220 CFM)
- Heat exchanger
- Hexagonal counterflow plastic plate
- Thermal efficiency
- Up to 90%
- Fans
- EC motor-driven
- Body
- New-generation EPP, high thermal insulation, lightweight
- Installation
- Vertical / horizontal, left / right in one unit
- Standard equipment
- G4 filter, bypass damper, temperature and humidity sensors
- Operating modes
- Heat recovery, free cooling, humidity boost, defrost
- Controls
- Wi-Fi with mobile app · ModBus
- Options
- Additional sensors and functional modules; electric pre-heater for extended freezing
04Model data
Figures from
the catalogue.
As published in the SenseAir technical catalogue.
| Model | Max. airflowm³/h | Max. thermal efficiency% | Energy class | Max. electrical powerW | Duct connectionsmm | Dimensions (L × W × H)mm | Weightkg |
|---|---|---|---|---|---|---|---|
| SenseAir | 375 | 90 | A+ | 150 | Ø160 / Ø125 | 550 × 500 × 850 | 18 |
Max. airflow at 100 Pa. 230 V AC 50 Hz, 0.7 A. Two G4 filters (F7 optional). EPP casing. Operating temperature −25 to +60 °C. The catalogue gives no sound data.
